AARONIA HF60105 SPECTRUM ANALYZER
Frequency range: 1 MHz to 9,4 GHz
Max measurement range: -155dBm
Typ. accuracy: +/- 1dB
Input connector: SMA(f) 50 ohms
AARONIA DFG 4060 DIRECTIONAL FIELD GENERATOR
Frequency range: 400 MHz to 6 GHz
Up to 3V/m output power (1m distance)
Highest power level: +18dBm
Smallest power level: -45dBm
Up to 63dB dynamic range
Modulations: AM, FM, PM
SMA-connector
AARONIA PBS 1 EMC SNIFFER SET
Isotropic E-field Probe Maximum Resonance Frequency 9 GHz
6 mm Magnetic Field Probe Maximum Resonance Frequency 6 GHz
12 mm Magnetic Field Sniffer Maximum Resonance Frequency 2.6 GHz
25 mm Magnetic Field Probe Maximum Resonance Frequency 500 MHz
50 mm Magnetic Field Probe Maximum Resonance Frequency 700 MHz
Connector: 50 Ohms SMB socket (m)
AARONIA OMNILOG 90200 OMNIDIRECTIONAL ANTENNA
Frequency Range 700 MHz - 2.5 GHz
Design Omni
Gain (max.) 2 dBi
Connector SMA (m)
AARONIA NF5035S SPECTRUM ANALYZER
Frequency range: 1 Hz to 1 MHz
Typ. level range E-Field: 0,1 V/m to 5.000 V/m @ 50 Hz
Typ. level range H-Field: 1 pT to 500 μT @ 50Hz
Typ. level range Analog in: 200 nV to 200 mV / -150 dBm (Hz)
Typ. accuracy: 3%
65 MSPS
Connector: 50 Ohms SMA
HPC CENTER
CPU: Intel Xeon Silver 4410T
GPU: NVIDIA GeForce RTX 4090
GIGABYTE MS03-CE0 MOTHERBOARD
64GB (2X32GB) DDR5 4800MHz
HP Z840 WORK STATION
2x Intel Xeon E5-2670 v3
172 GB RAM (DDR4)
NVIDIA Quadro K 620 2GB
1TB SATA 6Gb/s 7200rpm
